Servo Gearboxes
PL2-FS Planetary Gearbox with Input Flange
Planetary gearboxes PL2-FS with extremely low backlash, high transmission precision and sophisticated design for highly dynamic servo applications. Virtually unlimited number of gear ratios, with two-, three- or even four-stage gearboxes, ratios of up to 10,000:1 can be achieved.
The unique TANDLER design allows for the motor flange plate and two-part coupling to be machined to the customer specification allowing for most motor specifications to be accommodated.
Features & Benefits
Low backlash
Revolutionary motor mount. A flexible motor connection eliminates misalignment and gear deflection.
QPQ Nitriding process provides protection against high moisture environments.
Cast iron housing. Provides superior torsional rigidity over aluminium housings.
Lifetime Lubrication
Standard models can be modified or special versions produced for maximum design versatility.
Any ratio using combinations of 3:1 to 10:1 are possible.
Specifications
Maximum torque up to 1750Nm*
Speed up to 3,000 r/min**
7 standard sizes with ratios from 3:1 to 10,000:1 in up to four stages.
*/** Higher speed and torque on request
Standard backlash 6-8 arc min.
Reduced backlash down to 3 arc min.
Flange plate and two part coupling machined to suit most motor sizes
Output shaft can be supplied with key or as a plain shaft
